A VOICE COIL WINDING MACHINE IS AN ESSENTIAL TOOL FOR MANUFACTURING HIGH-QUALITY AUDIO AND ELECTROMECHANICAL DEVICES.
A Voice Coil Winding Machine is a precision-engineered device used to manufacture voice coils, which are essential components in speakers, microphones, actuators, and other audio or electromechanical devices.
The machine automates the winding of fine copper or aluminum wire onto a coil former (bobbin) with extreme accuracy and consistency, ensuring optimal electrical and mechanical performance.
A voice coil—a key component in loudspeakers, headphones, microphones, and other audio devices. This machine ensures uniform tension, accurate turns, and high-speed production of voice coils, which are essential for converting electrical signals into sound.
Technical Particulars:
A Voice Coil Winding Machine is an essential tool for manufacturing high-quality audio and electromechanical devices. A complete machine comprise the following main components:
- High Precision & Accuracy
- Automatic Tension Control
- Programmable Winding Parameters
- Multi-Layer Winding Support
- Touchscreen & PLC Control
| SPECIFICATION | |
|---|---|
| Winding Type | Automatic / Semi-Automatic |
| Wire Material | Copper / Aluminum |
| Wire Diameter | 0.02 mm – 1.0 mm |
| Coil Forming Type | Round / Oval / Rectangular |
| Winding Speed | Up to 10,000 RPM (Depending on model) |
| Bobbin Diameter | 5 mm – 100 mm (Customizable) |
| Winding Pitch Accuracy | ± 0.01 mm |
| Control System | PLC / Touchscreen HMI |
| Power Supply | 220V / 380V, 50/60Hz |
| Weight | 50 kg – 300 kg (Depending on Configuration) |
| Layer Insulation | Optional Automatic Paper or Film Insertion |
